Dongguan Cableforce Electronics Co., Ltd
Sales & Support:
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | CABLEFORCE |
| Certification: | UL Certified, CUL Certified, CE/ EMC, IP67, IP69K |
| Model Number: | MC04C5LRSDSB22CG10-C5E |
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | Negotiated |
| Packaging Details: | Our standard packing: Individual part with transparent PE bag with label, OEM packing available. |
| Delivery Time: | 2~3 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 60000 pcs/month |
| Coding: | D Coding | Gender: | Male To Male |
|---|---|---|---|
| Wire Gauge: | 0.34mm²(AWG 22) CAT 5E SFTP | Type: | M12 D Code Cable Connector |
| Application: | Profinet Ethernet | Characteristic Impedance: | 100Ω ±15 |
| Over-molding: | TPU | Reference Standard: | IEC 61076-2-101 |
| Contact Carrier: | TPU+GF | Screw Nut: | Brass, CNC, Nickel-plated |
| Contact: | Brass | ||
| High Light: | 4x22AWG Right Angled Connector,PUR 1M Right Angled Connector,Profinet M12 Male Connector |
||
|
Connector Technical Data
|
|||||||||
| Model Number | MC04C5LRSDSB22CG10-C5E | ||||||||
| Contact No | 4 pin | ||||||||
| Coding |
D coded
|
||||||||
|
Contact Resistance
|
≤10mΩ
|
||||||||
|
Characteristic Impedance
|
150Ω ±15
|
||||||||
|
Wire Gauge
|
0.34mm²(AWG 22)
|
||||||||
|
Type
|
M12 D Code Cable Connector
|
||||||||
|
Contact Carrier
|
TPU+GF
|
||||||||
|
Screw Nut
|
Brass,CNC,Nickel-plated
|
||||||||
|
Contact
|
Brass(Male), Phosphor bronze(Female)
|
||||||||
|
Pollution Degree
|
3 | ||||||||
|
Protection Degree
|
IP67,IP68
|
||||||||
● IP67 IP68 IP69K and UL approvals
● 360° shielded or non-shielded versions are available
● TPU over molded and PA+GF or metal shell
● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test
● UV Resistant, Hydrolysis Resistant,Oil resistant
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
● RoHS, REACH compliant.
FAQ
● What is PROFIBUS and how it works?
Profibus (from process field bus) is a protocol for field bus communication in automation technology. Profibus links automation systems and controllers with decentralized field devices such as sensors, actuators, and encoders. Profibus networks exchange data using a single bus cable.
● What does the coding mean on M12 connectors?
This coding prevents incorrect mating on products. In addition, shielding is available in most coded M12 connectors. For example, X-coded connectors are specifically shielded by the design of their coding.
● What is difference between PROFIBUS and Ethernet?
PROFINET is a fieldbus system which is based on Ethernet. PROFINET is one of the many industrial ethernet systems out there, which is often compared to PROFIBUS. PROFINET is a full duplex system. Because it's ethernet based, PROFINET can operate on a much higher transmission speed than PROFIBUS.
