IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector

IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector

  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
  • IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector
Product Details:
Place of Origin: Guangdong, China
Brand Name: Cableforce
Certification: UL Certified, CUL Certified, CE/ EMC, IP67, IP69K
Model Number: MD12C2LSAB
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: 100 - 499 Pieces:$6.94
Packaging Details: Large carton:Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Delivery Time: 7 work days
Payment Terms: T/T
Contact Now
Detailed Product Description
Coding: A-Coding Application: Sensors, Actuators, Encoders, Servo Motors
Gender: Male Type: M16 Field Wireable Connector
Over-molding: TPU Screw Nut: Brass,CNC,nickel-plated
Contact Carrier: PA66+GF Protection Degree: IP65
Pins: 4P, 5P, 7P, 3P, 8P, 2P, 6P, 8P, 12P Standard: IEC 61076-2-106
Wire Gauge: 24AWG/0.25mm2 Rated Temperature: -40°C ~ +85°C
Contact Resistance: ≤5mΩ Insulation Resistance: ≥100 MΩ
High Light:

EMI Shielded M16 Circular Connector

,

IP65 M16 Circular Connector

,

Plastic M16 12 Pin Male Connector

IP65 EMI-Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Assembly Cable Connector​


Description



● IP67 and UL approvals
● 2, 3, 4, 5, 6, 7, 8, 9, 12 poles are available

● TPU over molded and PA+GF or metal shell

● Anti-vibration locking screw design

● Operating voltage 630V/300V/250V

● Current range: 20A,16A,12A,8A,4A
● Metal Shielded Housing



CABLEFORCE Products Features

Tailor made material to meet various application conditions
● Gold-plated solid brass or phosphor bronze contacts ≥ 600 times mating life
● Durable cable material suitable for Drag Chain moving and bending demands
● Good stripping and terminating properties
● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test
● UV Resistant, Hydrolysis Resistant,Oil resistant
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
● RoHS, REACH compliant.
IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 0IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 1IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 2IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 3IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 4IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 5IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 6IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 7IP65 EMI Shielded M16 Circular Connector Plastic Male Plug 12pin Gland Connector 8
