EMI Shielded 5m 4Pin Female Connector Cable Ip67 M12 For Sensor Actuator

EMI Shielded 5m 4Pin Female Connector Cable Ip67 M12 For Sensor Actuator

  • EMI Shielded 5m 4Pin Female Connector Cable Ip67 M12 For Sensor Actuator
EMI Shielded 5m 4Pin Female Connector Cable Ip67 M12 For Sensor Actuator
Product Details:
Place of Origin: Guangdong, China
Brand Name: CABLEFORCE
Certification: UL Certified, CUL Certified, CE/ EMC, IP67, IP69K
Model Number: YF2A24-050UB4XLEAX
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiated
Packaging Details: Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Delivery Time: 2~3 weeks
Payment Terms: T/T
Supply Ability: 60000 pcs/month
Contact Now
Detailed Product Description
Contacts Poles: 4 Pin Cable Length: 5 Meters
Connector Gender: Female Connector Cable Jacket: PUR
Keyway Coding: A Coded EMC Shielding: Un-shielded
Cable Color: Black, Orange, Yellow, Gray Reference Standard: IEC 61076-2-101
High Light:

Actuator Female Connector Cable

,

Ip67 Female Connector Cable

,

4Pin M12 Sensor Actuator Cable

5m 4Pin Sensor Actuator Cable Ip67 Ip68 M12 A Coded Female Connector EMI-Shielded

Connector Technical Data
Part Number
2095729
Connectors No.
4Pin
Rated Current
4A
Rated Voltage
250V
Impulse Voltage
2500V
Wire Gauge
0.34mm²(AWG 22)
Over-molding
TPU
Contact Carrier
TPU+GF
Screw Nut
Brass,CNC,Nickel-plated
Contact
Brass(Male), Phosphor bronze(Female)
Contact Plating
Au(Gold)
Protection Degree
IP67,IP68


Description

M12 circular connectors are one of the most widely used sizes for circular connectors. The M12 size is available in coding variants for all industrial lifelines – for power, signals and data. IP65/67 protected and packaged in a rugged metal housing, they provide a completely reliable connection when used in demanding applications.

M12 circular connectors with M12 locking thread of Automation, Process control, Industrial Ethernet, Railway CCTV, Boat cabling etc..

M12 series with wide product range of panel type connectors for sensor/actuator components offers comprehensive solutions for M12 devices connection.M12 panel mount connectors are available for the device connection for sensor/actuator boxes, field-bus modules and industrial controllers. These connectors can be mechanically integrated into the device design "seamlessly", and are also designed for economical PCB assembly with rear mount type and front mount type.





CABLEFORCE Products Features


A,B,D,X,S,T coding available

● Easily installable connector system

● Environment protection IP67 and IP68

● Connector ranges include male and female connectors in 2 3 4 5 8 and 12 positions and Y connectors

● All connctors also available with silver plated contacts for higher conductivity

● Alternative mount arrangements for solder cup or PCB

● Panel Mount and distribution version available

● Shield reliable





FAQ



What is a M12 connector?

The M12 connector is a circular connector with a 12-mm locking thread that is used primarily in factory automation applications for actuators, sensors, industrial ethernet, and Fieldbus. M12 connectors are designed for washdown and corrosive environments. They are available with 3, 4, 5, 8, and 12 pins.



What does the coding mean on M12 connectors?

This coding prevents incorrect mating on products. In addition, shielding is available in most coded M12 connectors. For example, X-coded connectors are specifically shielded by the design of their coding.



What is a sensor cable?

Sensor cable is a cable construction designed for optimal performance of signal/data transmission from a sensor, transducer, or transmitter to a control unit. Pressure, liquid, temperature, and flow are just a few of the measurements that can be taken.





EMI Shielded 5m 4Pin Female Connector Cable Ip67 M12 For Sensor Actuator 0
