10m 4Pin Unshielded PUR Jacket Cable M12 A Coded Female Connector

10m 4Pin Unshielded PUR Jacket Cable M12 A Coded Female Connector

  • 10m 4Pin Unshielded PUR Jacket Cable M12 A Coded Female Connector
10m 4Pin Unshielded PUR Jacket Cable M12 A Coded Female Connector
Product Details:
Place of Origin: Guangdong, China
Brand Name: CABLEFORCE
Certification: UL Certified, CUL Certified, CE/ EMC, IP67, IP69K
Model Number: YF2A14-100UB3XLEAX
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiated
Packaging Details: Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Delivery Time: 2~3 weeks
Payment Terms: T/T
Supply Ability: 60000 pcs/month
Contact Now
Detailed Product Description
Contacts Poles: 4 Pin Cable Length: 10 Meters
Connector Gender: Female Cable Jacket: PUR
Keyway Coding: A Coded EMC Shielding: Un-shielded
Cable Color: Black, Orange, Yellow, Gray Reference Standard: IEC 61076-2-101
High Light:

10m Unshielded PUR Jacket Cable

,

M12 A Coded PUR Jacket Cable

,

4A Sensor Actuator Cable

10m 4Pin Sensor Actuator Cable PUR Jacket M12 A Coded Female Connector Unshielded

Connector Technical Data
Part Number
2095609
Connectors No.
4Pin
Rated Current
4A
Rated Voltage
250V
Impulse Voltage
2500V
Wire Gauge
0.34mm²(AWG 22)
Over-molding
TPU
Contact Carrier
TPU+GF
Screw Nut
Brass,CNC,Nickel-plated
Contact
Brass(Male), Phosphor bronze(Female)
Contact Plating
Au(Gold)
Protection Degree
IP67,IP68


Description

M12 circular connectors with M12 locking thread of Automation, Process control, Industrial Ethernet, Railway CCTV, Boat cabling etc..
The series of CABLEFORCE M12 connector offers many different cable connectors configuration , panel-mounted receptacles, field attachable / installable connectors with industry - standard A B D X S T K L and Y keyway coding options.

M12 series with wide product range of panel type connectors for sensor/actuator components offers comprehensive solutions for M12 devices connection.M12 panel mount connectors are available for the device connection for sensor/actuator boxes, field-bus modules and industrial controllers. These connectors can be mechanically integrated into the device design "seamlessly", and are also designed for economical PCB assembly with rear mount type and front mount type.





CABLEFORCE Products Features


● Tailor made material to meet various application conditions
● Gold-plated solid brass or phosphor bronze contacts ≥ 600 times mating life
● Durable cable material suitable for Drag Chain moving and bending demands
● Good stripping and terminating properties
● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test
● UV Resistant, Hydrolysis Resistant,Oil resistant
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
● Cable material: PUR or PVC





FAQ



What is a M12 connector?

The M12 connector is a circular connector with a 12-mm locking thread that is used primarily in factory automation applications for actuators, sensors, industrial ethernet, and Fieldbus. M12 connectors are designed for washdown and corrosive environments. They are available with 3, 4, 5, 8, and 12 pins.



What does the coding mean on M12 connectors?

This coding prevents incorrect mating on products. In addition, shielding is available in most coded M12 connectors. For example, X-coded connectors are specifically shielded by the design of their coding.



What is a sensor cable?

Sensor cable is a cable construction designed for optimal performance of signal/data transmission from a sensor, transducer, or transmitter to a control unit. Pressure, liquid, temperature, and flow are just a few of the measurements that can be taken.
