Place of Origin: | Guangdong, China |
Brand Name: | CABLEFORCE |
Certification: | UL Certified, CUL Certified, CE/ EMC, IP67, IP69K |
Model Number: | MC04C2LCTB16CK30 |
Minimum Order Quantity: | 100 |
---|---|
Price: | Negotiated |
Packaging Details: | Our standard packing: Individual part with transparent PE bag with label, OEM packing available. |
Delivery Time: | 2~3 weeks |
Payment Terms: | T/T |
Supply Ability: | 60000 pcs/month |
Contacts Poles: | 4 Pin | Cable Length: | 3M |
---|---|---|---|
Connector Gender: | Female | Cable Jacket: | PVC, PUR |
Keyway Coding: | T Code | Reference Standard: | IEC 61076 2 111 |
Cable Color: | Black | Termination: | Crimping |
High Light: | IP67 Sensor Actuator Cable,M12 Connector Sensor Actuator Cable,12A M12 4 Pole Connector |
Connector Technical Data
|
|||||||||
Model Number
|
MC04C2LCTB16CK30
|
||||||||
Connectors No.
|
4 Pin
|
||||||||
Locking System
|
M12×1.0 Screw
|
||||||||
Rated Voltage |
63V AC
|
||||||||
Impulse Voltage | 1500V | ||||||||
Wire Gauge
|
1.5mm²
|
||||||||
Over molding
|
TPU
|
||||||||
Insulation Resistance
|
≥100MΩ
|
||||||||
Contact Resistance
|
≤5mΩ
|
||||||||
Contact Carrier
|
PA66 + GF | ||||||||
Contact Plating
|
Au(Gold)
|
||||||||
Protection Degree
|
IP67,IP68
|
● Anti vibration loking screw design
● 360° Shielded or non shilded versions are available
● 2P, 2+3P, 3P, 4P, 5P, 8P, 12P, 17P poles per connector are avaliable
● Customized cable length, with PUR, PVC, LSZH, EtherNet, Profinet
● Operating voltage: 20A, 16A, 12A, 8A, 4A, 2A, 1.5A
FAQ
● What’s the PUR?
A PUR cable is a flexible, silicone, and halogen-free cable with PUR outer sheath polypropylene conductor insulation. It is oil and flame resistant and can be used in drag chain applications with minimal bend radius. PUR cables are very well suited for flexible applications in robotics, machine tools and metal cutting manufacturing
●What is coding in M12 connectors?
Several styles of coding exist in M12 connectors. This coding prevents incorrect mating on products. In addition, shielding is available in most coded M12 connectors. For example, X-coded connectors are specifically shielded by the design of their coding.
