Profibus Stainless M12 Circular Connector B Code PG9 Male Panel IP67

Profibus Stainless M12 Circular Connector B Code PG9 Male Panel IP67

  • Profibus Stainless M12 Circular Connector B Code PG9 Male Panel IP67
Profibus Stainless M12 Circular Connector B Code PG9 Male Panel IP67
Product Details:
Place of Origin: Guangdong, China
Brand Name: CABLEFORCE
Certification: CUL Certified, CE/ EMC, IP67
Model Number: MC05P2LSBBP9-22W10
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiated
Packaging Details: Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Delivery Time: 2~3 weeks
Payment Terms: T/T
Supply Ability: 60000 pcs/month
Contact Now
Detailed Product Description
Contacts Poles: 05 Pin Cable Length: 1M
Connector Gender: Female Connector Contact Carrier: PA66, GF
Keyway Coding: B Coding Tightening Torque: 0.6Nm
Cable Color: Brown, White, Blue, Black, Gray Wire Gauge: 0.25 M㎡
High Light:

Stainless M12 Circular Connector

,

IP67 M12 Circular Connector

,

PG9 Male Profibus M12 Connector

Profibus Stainless M12 Circular Connector B Code PG9 Male Panel

Connector Technical Data
Model Number
MC05P2LSBBP9-22W10
Connectors No.
5 Pin
Rated Current
4A
Rated Voltage
60V
Impulse Voltage
2500V
O ring FKM, Silicon
Insulation resistance 100MΩ
Contact resistence 5MΩ
Termination Soldering
Contact Phosphor bronze
Screw nut Brass, CNC, Nickled plated


Description

They are available with 3, 4, 5, 8 and 12 pins. While higher pin counts are not planned, other locking styles such as bayonet and push-pull are continuously under development. M12 connectors are circular connectors with a 12-mm locking thread used for sensors, actuators, Fieldbus and industrial Ethernet, primarily in factory automation applications. Often with ratings ofIP65, IP68 and IP69K, they are ideal for washdown and corrosive environments.



Mechanical Performance


Coupling method: threaded connection

Direction: Straight/Angled

Mechanical operation: >500 mating cycles

Wire gauge for solder cable type: 0.140.25/0.34/0.5mm²/(26/24/22/20AWG)



FAQ



● What is a panel interface connector?

A panel interface connector (PIC) is a device that typically mounts to the outside of a control panel in a manufacturing or other automation setting. Once installed, the PIC, which houses convenient pass-through connections, allows the user to interface with the computer, PLC, or other programmable devices inside the control panel without opening the panel door.
