Automation M12 4 Pin Male Connector Flange Type PG9 Male Panel Mount Connector

Automation M12 4 Pin Male Connector Flange Type PG9 Male Panel Mount Connector

  • Automation M12 4 Pin Male Connector Flange Type PG9 Male Panel Mount Connector
Automation M12 4 Pin Male Connector Flange Type PG9 Male Panel Mount Connector
Product Details:
Place of Origin: Guangdong, China
Brand Name: CABLEFORCE
Certification: CUL Certified, CE/ EMC, IP67
Model Number: MC04P2LSABF-22W02
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: Negotiated
Packaging Details: Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Delivery Time: 2~3 weeks
Payment Terms: T/T
Supply Ability: 60000 pcs/month
Contact Now
Detailed Product Description
Contacts Poles: 04 Pin Cable Length: 0.2M
Connector Gender: Female Connector Contact Carrier: PA66+GF
Keyway Coding: A Coding Tightening Torque: 0.6Nm
Cable Color: Brown, White, Blue, Black Wire Gauge: 0.34m㎡
High Light:

A Code M12 4 Pin Male Connector

,

Stainless M12 4 Pin Male Connector

,

PG9 Male M12 Panel Mount Connector

Automation M12 Circular Connector Flange Type PG9 Male Panel Mount Connector

Connector Technical Data
Model Number
MC04P2LSABF-22W02
Connectors No.
4 Pin
Rated Current
4A
Rated Voltage
250V
Impulse Voltage
2500V
O ring FKM, Silicon
Insulation resistance 100MΩ
Contact resistence 5MΩ
Termination Soldering
Contact Phosphor
Protection degree
IP67, IP68



Description

M12 connectors are circular connectors with a 12-mm locking thread used for sensors, actuators, Fieldbus and industrial Ethernet, primarily in factory automation applications. Often with ratings ofIP65, IP68 and IP69K, they are ideal for washdown and corrosive environments. They are available with 3, 4, 5, 8 and 12 pins. While higher pin counts are not planned, other locking styles such as bayonet and push-pull are continuously under development.



CABLEFORCE Products Features


• IP68 achieved without seal rings (PG and metric only)¹

• Trapezoidal thread with high torque guarantees tight and permanent fit of the dome nut

• Gas tight and watertight Applications: Machines and devices



FAQ



Which direction do the system panel cables connect?

The system panel cables are not keyed so can be plugged in any direction. Except for the LED cables, the system panel connector cables can be plugged in any direction. If the LED cables are plugged in backward, the LED light will not work. Usually, with most modern motherboards, you can identify what cable goes where by looking at the motherboard for a + and a - symbol. The colored wire (powered wire) would connect to the + symbol and a white or black cable (ground) would connect to the - symbol.
