| Contacts Poles: | 4 Pin | Gender: | Female |
|---|---|---|---|
| Wire Color: | Brown, White, Blue, Black | Keyway Coding: | A Coding |
| Locking System: | Screw | Wire Gauge: | 0.75 M㎡-1.25 M㎡ |
| Contacts Plating: | Gold | Over Molding: | TPU |
| High Light: | PG13.5 Mini Change Connectors,Waterproof Mini Change Connectors |
||
|
Connector Technical Data
|
|||||||||
|
Model Number
|
MF04P2LCAB16W05 | ||||||||
|
Connectors No.
|
A Code
|
||||||||
| Wire guage | AWG 16, AWG 18 | ||||||||
| Rated Currrent | 13A, 8A | ||||||||
|
Rated Voltage
|
300V
|
||||||||
|
Impulse Voltage
|
2500V
|
||||||||
| Screw nut | Brass, CNC, nickel plated | ||||||||
| Over molding | TPU | ||||||||
| Contact carrier | TPU+GF | ||||||||
| Contect | Phosphor bronze | ||||||||
| Contacts plating | Au | ||||||||
| O ring | FKM Silicon O Ring | ||||||||
A panel mount receptacle enables you to plug connectors directly into a device wall or free-hanging connector for in-the-field assembly. The process involves cutting a hole in the surface of the electrical device and placing the receptacle through or against the hole. This type of mount can be installed almost anywhere on the product chassis and is well-suited for products that require IP-rated protection from dust or water ingress.
Plug housing
Coupling nut
Receptacle housing
Jam nut
Mounting gasket/O-ring
Contacts
Connector interface sealing O-ring
FAQ
● What is the panel mount receptacle?
A receptacle is a plug-like apparatus that allows an electrical device to connect with a supply of electricity.
A connector is a plug-like apparatus that affixes to a receptacle to complete an electrical circuit and deliver electricity.
● What are the pros and cons of Metal vs plastic?
Metal has a higher tensile strength than plastic. Stainless steel is durable and easy to clean. More likely to require post-fabrication finishing like de-burring and painting which could add time and cost to the project.
